FAG 20309-TVP-C3

FAG 20309-TVP-C3
FAG 20309-TVP-C3 rulman resim 1
FAG 20309-TVP-C3 rulman resim 2
FAG 20309-TVP-C3 rulman resim 3
FAG 20309-TVP-C3 rulman resim 4
Fiyatı: 5,368.48 ₺
Özellikler
Marka FAG
Ürün No 20309-TVP-C3 FAG
Üretici No 0167021150030
EAN 4012801286749
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 45
Dış (D) MM 100
En (B) MM 25
İç (d) Inch 1.7717
Dış (D) Inch 3.937
En (B) Inch 0.9843
Ağırlık 0.904 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 25
Radial Static Load Rating C0r (N) 94000
Radial Dynamic Load Rating Cr (N) 87000
Temel statik yük derecesi, radyal (C 0r) "94000.0000"
Hız sınırlaması (n G) 6500
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
C3 Internal Clearance Larger Than Normal
