FAG 20318-MB

FAG 20318-MB
FAG 20318-MB rulman resim 1
FAG 20318-MB rulman resim 2
FAG 20318-MB rulman resim 3
Fiyatı: 19,748.56 ₺
Özellikler
Marka FAG
Ürün No 20318-MB FAG
Üretici No 0190142870000
EAN 4012801287081
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 90
Dış (D) MM 190
En (B) MM 43
İç (d) Inch 3.5433
Dış (D) Inch 7.4803
En (B) Inch 1.6929
Ağırlık 6.12 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 43
Radial Static Load Rating C0r (N) 360000
Radial Dynamic Load Rating Cr (N) 300000
Temel statik yük derecesi, radyal (C 0r) "360000.0000"
Hız sınırlaması (n G) 3500
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
MB Solid Brass Cage, Guidance On Inner Ring
