FAG 21314-E1-XL-K-TVPB
Fiyatı: 2,963.79 ₺
Özellikler
| Marka | FAG |
| Ürün No | 21314-E1-XL-K-TVPB FAG |
| Üretici No | 0190059620000 |
| Alternatif Kodu |
21314-E1-K-TVPB |
| EAN | 4026677809452 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 70 |
| Dış (D) MM | 150 |
| En (B) MM | 35 |
| İç (d) Inch | 2.7559 |
| Dış (D) Inch | 5.9055 |
| En (B) Inch | 1.378 |
| Ağırlık | 2.95 kg |
| Sıkıntı | K - 1:12 Konik Delik (Çoğu Tip İçin Standart) |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 35 |
| Radial Static Load Rating C0r (N) | 270000 |
| Radial Dynamic Load Rating Cr (N) | 250000 |
| Temel statik yük derecesi, radyal (C 0r) | "270000.0000" |
| Hız sınırlaması (n G) | 6200 |
| Referans Hızı (n u03d1r) | 3950 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 213..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12 |
| E1 | Increased Capacity Design |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
FAG 21314-E1-XL-K
3.127 kg
70x150x35 mm
FAG 20314-MB
3.085 kg
70x150x35 mm
FAG 21314-E1-XL-C3
3.127 kg
70x150x35 mm
FAG 21314-E1-XL-K-TVPB-C3
2.95 kg
70x150x35 mm
FAG 21314-E1-XL
3.127 kg
70x150x35 mm
FAG 21314-E-K-TVPB
2.95 kg
70x150x35 mm
FAG 21314-E1-TVPB-C3
2.95 kg
70x150x35 mm
FAG 21314-E1-TVPB
2.95 kg
70x150x35 mm
FAG 21314-E1-XL-TVPB-C3
2.95 kg
70x150x35 mm
FAG 21314EK-TVPB
2.95 kg
70x150x35 mm
FAG 21314-E1-K
3.127 kg
70x150x35 mm
FAG 21314K
3.127 kg
70x150x35 mm
FAG 21314E1K-TVPB
2.95 kg
70x150x35 mm
FAG 21314E1
3.127 kg
70x150x35 mm
FAG 21314-E-K-TVPB-C3
2.95 kg
70x150x35 mm
FAG 21314-E1-K-TVPB-C3
2.95 kg
70x150x35 mm
FAG 21314E1K
3.127 kg
70x150x35 mm
FAG 21314E1TVPB
2.95 kg
70x150x35 mm
FAG 20314MB
3.085 kg
70x150x35 mm
FAG 21314E1-TVPB
2.95 kg
70x150x35 mm
FAG 21314E1K-TVPB-C3
2.95 kg
70x150x35 mm
FAG 21314E1TVPB-C3
2.95 kg
70x150x35 mm
FAG 20314M
3.085 kg
70x150x35 mm
FAG 21314-E1-XL-TVPB
2.95 kg
70x150x35 mm
FAG 21314-E1-K-TVPB
2.95 kg
70x150x35 mm
FAG 21314E1-C3
3.127 kg
70x150x35 mm
FAG 21314K-C3
2.95 kg
70x150x35 mm
FAG 21314TV
2.95 kg
70x150x35 mm
