FAG 21320E1TVPB-C3
Fiyatı: 7,449.94 ₺
Özellikler
| Marka | FAG |
| Ürün No | 21320E1TVPB.C3 FAG |
| Kategori | Küresel Makaralı |
| İç (d) MM | 100 |
| Dış (D) MM | 215 |
| En (B) MM | 47 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 8.4646 |
| En (B) Inch | 1.8504 |
| Ağırlık | 8.19 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| E1 | Increased Capacity Design |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
| C3 | Internal Clearance Larger Than Normal |
