FAG 22206-E1-XL-C4

FAG 22206-E1-XL-C4
FAG 22206-E1-XL-C4 rulman resim 1
FAG 22206-E1-XL-C4 rulman resim 2
FAG 22206-E1-XL-C4 rulman resim 3
FAG 22206-E1-XL-C4 rulman resim 4
Fiyatı: 1,181.23 ₺
Özellikler
Marka FAG
Ürün No 22206-E1-XL-C4 FAG
Üretici No 0167033080040
Alternatif Kodu 22206-E1-C4
EAN 4026677804556
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 30
Dış (D) MM 62
En (B) MM 20
İç (d) Inch 1.1811
Dış (D) Inch 2.4409
En (B) Inch 0.7874
Ağırlık 0.28 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 20
Radial Static Load Rating C0r (N) 57000
Radial Dynamic Load Rating Cr (N) 64000
Temel statik yük derecesi, radyal (C 0r) "57000.0000"
Hız sınırlaması (n G) 12500
Referans Hızı (n u03d1r) 7800
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C4 Bearing Internal Clearance Greater Than C3
