FAG 22208-E1-XL-C4

FAG 22208-E1-XL-C4
FAG 22208-E1-XL-C4 rulman resim 1
FAG 22208-E1-XL-C4 rulman resim 2
FAG 22208-E1-XL-C4 rulman resim 3
FAG 22208-E1-XL-C4 rulman resim 4
FAG 22208-E1-XL-C4 rulman resim 5
Fiyatı: 1,230.53 ₺
Özellikler
Marka FAG
Ürün No 22208-E1-XL-C4 FAG
Üretici No 0167033910040
Alternatif Kodu 22208-E1-C4
EAN 4026677804693
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 40
Dış (D) MM 80
En (B) MM 23
İç (d) Inch 1.5748
Dış (D) Inch 3.1496
En (B) Inch 0.9055
Ağırlık 0.489 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 23
Radial Static Load Rating C0r (N) 91000
Radial Dynamic Load Rating Cr (N) 101000
Temel statik yük derecesi, radyal (C 0r) "91000.0000"
Hız sınırlaması (n G) 10500
Referans Hızı (n u03d1r) 6200
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C4 Bearing Internal Clearance Greater Than C3
