FAG 22209-E1-XL-C3

FAG 22209-E1-XL-C3
FAG 22209-E1-XL-C3 rulman resim 1
FAG 22209-E1-XL-C3 rulman resim 2
FAG 22209-E1-XL-C3 rulman resim 3
FAG 22209-E1-XL-C3 rulman resim 4
FAG 22209-E1-XL-C3 rulman resim 5
Fiyatı: 1,147.74 ₺
Özellikler
Marka FAG
Ürün No 22209-E1-XL-C3 FAG
Üretici No 0167034480030
Alternatif Kodu 22209-E1-C3
EAN 4026677804778
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 45
Dış (D) MM 85
En (B) MM 23
İç (d) Inch 1.7717
Dış (D) Inch 3.3465
En (B) Inch 0.9055
Ağırlık 0.539 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 23
Radial Static Load Rating C0r (N) 99000
Radial Dynamic Load Rating Cr (N) 104000
Temel statik yük derecesi, radyal (C 0r) "99000.0000"
Hız sınırlaması (n G) 10100
Referans Hızı (n u03d1r) 5600
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C3 Internal Clearance Larger Than Normal
