FAG 22215-E1-XL-TVPB

FAG 22215-E1-XL-TVPB
FAG 22215-E1-XL-TVPB rulman resim 1
FAG 22215-E1-XL-TVPB rulman resim 2
FAG 22215-E1-XL-TVPB rulman resim 3
FAG 22215-E1-XL-TVPB rulman resim 4
FAG 22215-E1-XL-TVPB rulman resim 5
Fiyatı: 2,459.60 ₺
Özellikler
Marka FAG
Ürün No 22215-E1-XL-TVPB FAG
Üretici No 0190164170000
Alternatif Kodu 22215-E1-TVPB
EAN 4026677853851
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 75
Dış (D) MM 130
En (B) MM 31
İç (d) Inch 2.9528
Dış (D) Inch 5.1181
En (B) Inch 1.2205
Ağırlık 1.61 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
