FAG 22220-E1-XL

FAG 22220-E1-XL
FAG 22220-E1-XL rulman resim 1
FAG 22220-E1-XL rulman resim 2
FAG 22220-E1-XL rulman resim 3
Fiyatı: 4,949.78 ₺
Özellikler
Marka FAG
Ürün No 22220-E1-XL FAG
Üretici No 0167042150000
Alternatif Kodu 22220-E1
EAN 4026677809162
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 100
Dış (D) MM 180
En (B) MM 46
İç (d) Inch 3.937
Dış (D) Inch 7.0866
En (B) Inch 1.811
Ağırlık 4.69 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 46
Radial Static Load Rating C0r (N) 475000
Radial Dynamic Load Rating Cr (N) 430000
Hız sınırlaması (n G) 4550
Referans Hızı (n u03d1r) 3150
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
