FAG 22222-E1-XL-K
Fiyatı: 5,340.40 ₺
Özellikler
| Marka | FAG |
| Ürün No | 22222-E1-XL-K FAG |
| Üretici No | 0167043390000 |
| Alternatif Kodu |
22222-E1-K |
| EAN | 4026677827241 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 110 |
| Dış (D) MM | 200 |
| En (B) MM | 53 |
| İç (d) Inch | 4.3307 |
| Dış (D) Inch | 7.874 |
| En (B) Inch | 2.0866 |
| Ağırlık | 6.65 kg |
| Sıkıntı | K - 1:12 Konik Delik (Çoğu Tip İçin Standart) |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 53 |
| Radial Static Load Rating C0r (N) | 600000 |
| Radial Dynamic Load Rating Cr (N) | 550000 |
| Temel statik yük derecesi, radyal (C 0r) | "600000.0000" |
| Hız sınırlaması (n G) | 4100 |
| Referans Hızı (n u03d1r) | 3000 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 222..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12 |
| E1 | Increased Capacity Design |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
FAG 22222-E1A-XL-M-C4
7.04 kg
110x200x53 mm
FAG 22222-E1-XL-C4
6.67 kg
110x200x53 mm
FAG 22222-E1A-XL-M-C3
7.04 kg
110x200x53 mm
FAG 22222-E1A-XL-K-M
7.04 kg
110x200x53 mm
FAG 22222-E1
6.67 kg
110x200x53 mm
FAG 22222-E1A-XL-M
7.04 kg
110x200x53 mm
FAG 22222-E1-K-C3
6.65 kg
110x200x53 mm
FAG 22222-E1-XL
6.67 kg
110x200x53 mm
FAG 22222-E1-XL-K-C3
6.65 kg
110x200x53 mm
FAG 22222-E1A-XL-K-M-C3
7.04 kg
110x200x53 mm
FAG 22222-E1-XL-C3
6.67 kg
110x200x53 mm
FAG 22222-E1-XL-K-C4
6.65 kg
110x200x53 mm
FAG 22222E1AK-M
7.04 kg
110x200x53 mm
FAG 22222K
6.68 kg
110x200x53 mm
FAG 22222EAS-M
7.04 kg
110x200x53 mm
FAG 22222-E1-C3
6.67 kg
110x200x53 mm
FAG 22222-E1A-M
7.04 kg
110x200x53 mm
FAG 22222ESK-C3
6.65 kg
110x200x53 mm
FAG 22222-E1A-K-M
7.04 kg
110x200x53 mm
FAG 22222E1AK-M-C3
7.04 kg
110x200x53 mm
FAG 22222E1K-C4
6.65 kg
110x200x53 mm
FAG 22222E1-C3
6.67 kg
110x200x53 mm
FAG 22222E1K-C3
6.65 kg
110x200x53 mm
FAG 22222-E1A-XL-MA-H123F-T41A-R70-90
7.04 kg
110x200x53 mm
FAG 22222E1-C4
6.67 kg
110x200x53 mm
FAG 22222 EK-C4
6.65 kg
110x200x53 mm
FAG 22222EAS-M-C4
7.04 kg
110x200x53 mm
FAG 22222ESK-TVPB-C3
6.65 kg
110x200x53 mm
