FAG 22224-E1A-XL-M-H40-C4
Fiyatı: 11,060.61 ₺
Özellikler
| Marka | FAG |
| Ürün No | 22224-E1A-XL-M-H40-C4 FAG |
| Üretici No | 0392459180040 |
| Alternatif Kodu |
22224-E1A-M-H40-C4 |
| EAN | 4026677859563 |
| Kategori | Küresel Makaralı |
| Ağırlık | 8.87 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W - No Lubrication Groove or Holes |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Radyal İç Oyun | C4 İç Oyun (C3ten Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 58 |
| Radial Static Load Rating C0r (N) | 740000 |
| Radial Dynamic Load Rating Cr (N) | 640000 |
| Temel statik yük derecesi, radyal (C 0r) | "740000.0000" |
| Hız sınırlaması (n G) | 3650 |
| Referans Hızı (n u03d1r) | 2700 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearing 222..-E1A-XL-M-H40, symmetric 2 outer ribs |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| M | Solid Brass Cage, Guided By Rollers |
| H40 | Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring |
| C4 | Bearing Internal Clearance Greater Than C3 |
