FAG 22228-E1-XL-K-C3

FAG 22228-E1-XL-K-C3
FAG 22228-E1-XL-K-C3 rulman resim 1
FAG 22228-E1-XL-K-C3 rulman resim 2
FAG 22228-E1-XL-K-C3 rulman resim 3
FAG 22228-E1-XL-K-C3 rulman resim 4
FAG 22228-E1-XL-K-C3 rulman resim 5
FAG 22228-E1-XL-K-C3 rulman resim 6
Fiyatı: 11,666.30 ₺
Özellikler
Marka FAG
Ürün No 22228-E1-XL-K-C3 FAG
Üretici No 0167045840030
Alternatif Kodu 22228-E1-K-C3
EAN 4026677827432
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 140
Dış (D) MM 250
En (B) MM 68
İç (d) Inch 5.5118
Dış (D) Inch 9.8425
En (B) Inch 2.6772
Ağırlık 13.05 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 68
Radial Static Load Rating C0r (N) 1040000
Radial Dynamic Load Rating Cr (N) 870000
Hız sınırlaması (n G) 3150
Referans Hızı (n u03d1r) 2250
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
C3 Internal Clearance Larger Than Normal
