FAG 22236-E1A-XL-K-M-C3
Fiyatı: 32,005.17 ₺
Özellikler
| Marka | FAG |
| Ürün No | 22236-E1A-XL-K-M-C3 FAG |
| Üretici No | 0386728710030 |
| Alternatif Kodu |
22236-E1A-K-M-C3 |
| EAN | 4026677866479 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 180 |
| Dış (D) MM | 320 |
| En (B) MM | 86 |
| İç (d) Inch | 7.0866 |
| Dış (D) Inch | 12.5984 |
| En (B) Inch | 3.3858 |
| Ağırlık | 29.72 kg |
| Sıkıntı | K - 1:12 Konik Delik (Çoğu Tip İçin Standart) |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 86 |
| Radial Static Load Rating C0r (N) | 1680000 |
| Radial Dynamic Load Rating Cr (N) | 1360000 |
| Temel statik yük derecesi, radyal (C 0r) | "1680000.0000" |
| Hız sınırlaması (n G) | 2470 |
| Referans Hızı (n u03d1r) | 1670 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearing 222..-E1A-XL-K-M, symmetric 2 outer ribs |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
| M | Solid Brass Cage, Guided By Rollers |
| C3 | Internal Clearance Larger Than Normal |
