FAG 22308-E1-XL-C4

FAG 22308-E1-XL-C4
FAG 22308-E1-XL-C4 rulman resim 1
FAG 22308-E1-XL-C4 rulman resim 2
FAG 22308-E1-XL-C4 rulman resim 3
FAG 22308-E1-XL-C4 rulman resim 4
FAG 22308-E1-XL-C4 rulman resim 5
Fiyatı: 1,892.18 ₺
Özellikler
Marka FAG
Ürün No 22308-E1-XL-C4 FAG
Üretici No 0167049910040
Alternatif Kodu 22308-E1-C4
EAN 4026677806642
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 40
Dış (D) MM 90
En (B) MM 33
İç (d) Inch 1.5748
Dış (D) Inch 3.5433
En (B) Inch 1.2992
Ağırlık 1 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 33
Radial Static Load Rating C0r (N) 149000
Radial Dynamic Load Rating Cr (N) 156000
Hız sınırlaması (n G) 7600
Referans Hızı (n u03d1r) 5500
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 223..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C4 Bearing Internal Clearance Greater Than C3
