FAG 22310-E1-XL-C3

FAG 22310-E1-XL-C3
FAG 22310-E1-XL-C3 rulman resim 1
FAG 22310-E1-XL-C3 rulman resim 2
FAG 22310-E1-XL-C3 rulman resim 3
FAG 22310-E1-XL-C3 rulman resim 4
FAG 22310-E1-XL-C3 rulman resim 5
Fiyatı: 2,218.94 ₺
Özellikler
Marka FAG
Ürün No 22310-E1-XL-C3 FAG
Üretici No 0167051300030
Alternatif Kodu 22310-E1-C3
EAN 4026677806833
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 110
En (B) MM 40
İç (d) Inch 1.9685
Dış (D) Inch 4.3307
En (B) Inch 1.5748
Ağırlık 1.75 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 40
Radial Static Load Rating C0r (N) 223000
Radial Dynamic Load Rating Cr (N) 229000
Hız sınırlaması (n G) 6300
Referans Hızı (n u03d1r) 4800
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 223..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C3 Internal Clearance Larger Than Normal
