FAG 22311-E1-XL

FAG 22311-E1-XL
FAG 22311-E1-XL rulman resim 1
FAG 22311-E1-XL rulman resim 2
FAG 22311-E1-XL rulman resim 3
FAG 22311-E1-XL rulman resim 4
FAG 22311-E1-XL rulman resim 5
FAG 22311-E1-XL rulman resim 6
FAG 22311-E1-XL rulman resim 7
FAG 22311-E1-XL rulman resim 8
Fiyatı: 2,560.27 ₺
Özellikler
Marka FAG
Ürün No 22311-E1-XL FAG
Üretici No 0167052200000
Alternatif Kodu 22311-E1
EAN 4026677807847
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 55
Dış (D) MM 120
En (B) MM 43
İç (d) Inch 2.1654
Dış (D) Inch 4.7244
En (B) Inch 1.6929
Ağırlık 2.23 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 43
Radial Static Load Rating C0r (N) 260000
Radial Dynamic Load Rating Cr (N) 265000
Hız sınırlaması (n G) 5800
Referans Hızı (n u03d1r) 4500
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 223..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
