FAG 22312-E1A-XL-M-C4
Fiyatı: 4,408.14 ₺
Özellikler
| Marka | FAG |
| Ürün No | 22312-E1A-XL-M-C4 FAG |
| Üretici No | 0190197500040 |
| Alternatif Kodu |
22312-E1A-M-C4 |
| EAN | 4026677848888 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 60 |
| Dış (D) MM | 130 |
| En (B) MM | 46 |
| İç (d) Inch | 2.3622 |
| Dış (D) Inch | 5.1181 |
| En (B) Inch | 1.811 |
| Ağırlık | 2.93 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Radyal İç Oyun | C4 İç Oyun (C3ten Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 46 |
| Radial Static Load Rating C0r (N) | 310000 |
| Radial Dynamic Load Rating Cr (N) | 310000 |
| Temel statik yük derecesi, radyal (C 0r) | "310000.0000" |
| Hız sınırlaması (n G) | 5400 |
| Referans Hızı (n u03d1r) | 4200 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearing 223..-E1A-XL-M, symmetric 2 outer ribs |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| M | Solid Brass Cage, Guided By Rollers |
| C4 | Bearing Internal Clearance Greater Than C3 |
FAG 22312-E1-XL-K
2.7 kg
60x130x46 mm
FAG 22312-E1A-XL-M-C3
2.93 kg
60x130x46 mm
FAG 22312-E1-XL-T41A
2.9098 kg
60x130x46 mm
FAG 22312-E1-XL-K-C4
2.7 kg
60x130x46 mm
FAG 22312-E1-XL-K-T41A
2.7 kg
60x130x46 mm
FAG 22312-E1-XL-C3
2.8 kg
60x130x46 mm
FAG 22312-E1-XL-K-C3
2.7 kg
60x130x46 mm
FAG 22312-E1-XL-C4
2.9098 kg
60x130x46 mm
FAG 22312-E1A-XL-M
2.93 kg
60x130x46 mm
FAG 22312-E1A-XL-K-M
2.91 kg
60x130x46 mm
FAG 22312-E1-K-T41A
2.7 kg
60x130x46 mm
FAG 22312-E1A-XL-K-M-C3
2.91 kg
60x130x46 mm
FAG 22312-E1A-XL-MA-T41A
2.9098 kg
60x130x46 mm
FAG 22312-E1-XL
2.8 kg
60x130x46 mm
FAG 22312ESK-C3
2.7 kg
60x130x46 mm
FAG 22312K
2.7 kg
60x130x46 mm
FAG 22312-E1A-K-M-C3
2.91 kg
60x130x46 mm
FAG 22312ES-TVPB-C4
2.8 kg
60x130x46 mm
FAG 22312E1AK-M-C3
2.91 kg
60x130x46 mm
FAG 22312E1A-M-C3
2.93 kg
60x130x46 mm
FAG 22312E1A-M
2.93 kg
60x130x46 mm
FAG 22312E1-C4
2.9098 kg
60x130x46 mm
FAG 22312-E1-K-C3
2.7 kg
60x130x46 mm
FAG 22312-E1A-M-C3
2.93 kg
60x130x46 mm
FAG 22312E1A-MA-T41A
2.9098 kg
60x130x46 mm
FAG 22312E1K-C3
2.7 kg
60x130x46 mm
FAG 22312E-T41A
2.9098 kg
60x130x46 mm
FAG 22312E1-T41A
2.9098 kg
60x130x46 mm
