FAG 22314-E1-XL-C2

FAG 22314-E1-XL-C2
FAG 22314-E1-XL-C2 rulman resim 1
FAG 22314-E1-XL-C2 rulman resim 2
FAG 22314-E1-XL-C2 rulman resim 3
FAG 22314-E1-XL-C2 rulman resim 4
FAG 22314-E1-XL-C2 rulman resim 5
Fiyatı: 4,556.86 ₺
Özellikler
Marka FAG
Ürün No 22314-E1-XL-C2 FAG
Üretici No 0190006850020
Alternatif Kodu 22314-E1-C2
EAN 4012802559699
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 70
Dış (D) MM 150
En (B) MM 51
İç (d) Inch 2.7559
Dış (D) Inch 5.9055
En (B) Inch 2.0079
Ağırlık 4.22 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C2 İç Oyun (Cnden Az)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 51
Radial Static Load Rating C0r (N) 390000
Radial Dynamic Load Rating Cr (N) 390000
Hız sınırlaması (n G) 4800
Referans Hızı (n u03d1r) 3700
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 223..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C2 Bearing Internal Clearance Smaller Than Normal
