FAG 22316-E1-XL-C3

FAG 22316-E1-XL-C3
FAG 22316-E1-XL-C3 rulman resim 1
FAG 22316-E1-XL-C3 rulman resim 2
FAG 22316-E1-XL-C3 rulman resim 3
FAG 22316-E1-XL-C3 rulman resim 4
FAG 22316-E1-XL-C3 rulman resim 5
FAG 22316-E1-XL-C3 rulman resim 6
Fiyatı: 4,617.18 ₺
Özellikler
Marka FAG
Ürün No 22316-E1-XL-C3 FAG
Üretici No 0167055990030
Alternatif Kodu 22316-E1-C3
EAN 4026677808639
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 80
Dış (D) MM 170
En (B) MM 58
İç (d) Inch 3.1496
Dış (D) Inch 6.6929
En (B) Inch 2.2835
Ağırlık 5.96 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 58
Radial Static Load Rating C0r (N) 510000
Radial Dynamic Load Rating Cr (N) 495000
Hız sınırlaması (n G) 4250
Referans Hızı (n u03d1r) 3400
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 223..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C3 Internal Clearance Larger Than Normal
