FAG 22318-E1-XL-K

FAG 22318-E1-XL-K
FAG 22318-E1-XL-K rulman resim 1
FAG 22318-E1-XL-K rulman resim 2
FAG 22318-E1-XL-K rulman resim 3
FAG 22318-E1-XL-K rulman resim 4
FAG 22318-E1-XL-K rulman resim 5
FAG 22318-E1-XL-K rulman resim 6
Fiyatı: 6,108.34 ₺
Özellikler
Marka FAG
Ürün No 22318-E1-XL-K FAG
Üretici No 0190063300000
Alternatif Kodu 22318-E1-K
EAN 4026677810694
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 90
Dış (D) MM 190
En (B) MM 64
İç (d) Inch 3.5433
Dış (D) Inch 7.4803
En (B) Inch 2.5197
Ağırlık 7.9 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 64
Radial Static Load Rating C0r (N) 630000
Radial Dynamic Load Rating Cr (N) 610000
Hız sınırlaması (n G) 3850
Referans Hızı (n u03d1r) 3000
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 223..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
