FAG 23034-E1A-XL-M

FAG 23034-E1A-XL-M
FAG 23034-E1A-XL-M rulman resim 1
FAG 23034-E1A-XL-M rulman resim 2
FAG 23034-E1A-XL-M rulman resim 3
FAG 23034-E1A-XL-M rulman resim 4
FAG 23034-E1A-XL-M rulman resim 5
FAG 23034-E1A-XL-M rulman resim 6
FAG 23034-E1A-XL-M rulman resim 7
Fiyatı: 14,578.10 ₺
Özellikler
Marka FAG
Ürün No 23034-E1A-XL-M FAG
Üretici No 0190011260000
Alternatif Kodu 23034-E1A-M
EAN 4026677832436
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 170
Dış (D) MM 260
En (B) MM 67
İç (d) Inch 6.6929
Dış (D) Inch 10.2362
En (B) Inch 2.6378
Ağırlık 12.6 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 67
Radial Static Load Rating C0r (N) 1230000
Radial Dynamic Load Rating Cr (N) 880000
Temel statik yük derecesi, radyal (C 0r) "1230000.0000"
Hız sınırlaması (n G) 2800
Referans Hızı (n u03d1r) 1890
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1A, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
M Solid Brass Cage, Guided By Rollers
