FAG 23120-E1-XL-K-TVPB-C3
Fiyatı: 5,551.94 ₺
Özellikler
| Marka | FAG |
| Ürün No | 23120-E1-XL-K-TVPB-C3 FAG |
| Üretici No | 0190065860030 |
| Alternatif Kodu |
23120-E1-K-TVPB-C3 |
| EAN | 4026677871848 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 100 |
| Dış (D) MM | 165 |
| En (B) MM | 52 |
| İç (d) Inch | 3.937 |
| Dış (D) Inch | 6.4961 |
| En (B) Inch | 2.0472 |
| Ağırlık | 4.2 kg |
| Sıkıntı | K - 1:12 Konik Delik (Çoğu Tip İçin Standart) |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 52 |
| Radial Static Load Rating C0r (N) | 570000 |
| Radial Dynamic Load Rating Cr (N) | 450000 |
| Temel statik yük derecesi, radyal (C 0r) | "570000.0000" |
| Hız sınırlaması (n G) | 4000 |
| Referans Hızı (n u03d1r) | 2750 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 231..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12 |
| E1 | Increased Capacity Design |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
| C3 | Internal Clearance Larger Than Normal |
