FAG 23126-E1-XL-TVPB-C3

FAG 23126-E1-XL-TVPB-C3
FAG 23126-E1-XL-TVPB-C3 rulman resim 1
FAG 23126-E1-XL-TVPB-C3 rulman resim 2
FAG 23126-E1-XL-TVPB-C3 rulman resim 3
FAG 23126-E1-XL-TVPB-C3 rulman resim 4
FAG 23126-E1-XL-TVPB-C3 rulman resim 5
FAG 23126-E1-XL-TVPB-C3 rulman resim 6
Fiyatı: 9,558.22 ₺
Özellikler
Marka FAG
Ürün No 23126-E1-XL-TVPB-C3 FAG
Üretici No 0190309830030
Alternatif Kodu 23126-E1-TVPB-C3
EAN 4026677871916
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 130
Dış (D) MM 210
En (B) MM 64
İç (d) Inch 5.1181
Dış (D) Inch 8.2677
En (B) Inch 2.5197
Ağırlık 8.11 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 64
Radial Static Load Rating C0r (N) 890000
Radial Dynamic Load Rating Cr (N) 680000
Temel statik yük derecesi, radyal (C 0r) "890000.0000"
Hız sınırlaması (n G) 3200
Referans Hızı (n u03d1r) 2110
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 231..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
