FAG 23128-E1A-XL-K-M

FAG 23128-E1A-XL-K-M
FAG 23128-E1A-XL-K-M rulman resim 1
FAG 23128-E1A-XL-K-M rulman resim 2
FAG 23128-E1A-XL-K-M rulman resim 3
FAG 23128-E1A-XL-K-M rulman resim 4
FAG 23128-E1A-XL-K-M rulman resim 5
FAG 23128-E1A-XL-K-M rulman resim 6
Fiyatı: 10,554.13 ₺
Özellikler
Marka FAG
Ürün No 23128-E1A-XL-K-M FAG
Üretici No 0190311650000
Alternatif Kodu 23128-E1A-K-M
EAN 4026677828392
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 140
Dış (D) MM 225
En (B) MM 68
İç (d) Inch 5.5118
Dış (D) Inch 8.8583
En (B) Inch 2.6772
Ağırlık 9.663 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 68
Radial Static Load Rating C0r (N) 1010000
Radial Dynamic Load Rating Cr (N) 760000
Temel statik yük derecesi, radyal (C 0r) "1010000.0000"
Hız sınırlaması (n G) 3000
Referans Hızı (n u03d1r) 1930
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 231..-E1A-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
K Tapered Bore, Taper 1:12
M Solid Brass Cage, Guided By Rollers
