FAG 23218-E1-XL-TVPB

FAG 23218-E1-XL-TVPB
FAG 23218-E1-XL-TVPB rulman resim 1
FAG 23218-E1-XL-TVPB rulman resim 2
FAG 23218-E1-XL-TVPB rulman resim 3
FAG 23218-E1-XL-TVPB rulman resim 4
FAG 23218-E1-XL-TVPB rulman resim 5
Fiyatı: 5,032.98 ₺
Özellikler
Marka FAG
Ürün No 23218-E1-XL-TVPB FAG
Üretici No 0167083000000
Alternatif Kodu 23218-E1-TVPB
EAN 4026677809711
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 90
Dış (D) MM 160
En (B) MM 52,4
İç (d) Inch 3.5433
Dış (D) Inch 6.2992
En (B) Inch 2.063
Ağırlık 4.4702 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 52,4
Radial Static Load Rating C0r (N) 520000
Radial Dynamic Load Rating Cr (N) 445000
Temel statik yük derecesi, radyal (C 0r) "520000.0000"
Hız sınırlaması (n G) 4250
Referans Hızı (n u03d1r) 2650
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 232..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
