FAG 23222-E1A-M-C3

FAG 23222-E1A-M-C3
FAG 23222-E1A-M-C3 rulman resim 1
FAG 23222-E1A-M-C3 rulman resim 2
FAG 23222-E1A-M-C3 rulman resim 3
FAG 23222-E1A-M-C3 rulman resim 4
FAG 23222-E1A-M-C3 rulman resim 5
FAG 23222-E1A-M-C3 rulman resim 6
Fiyatı: 9,236.66 ₺
Özellikler
Marka FAG
Ürün No 23222-E1A-M-C3 FAG
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 200
En (B) MM 69,8
İç (d) Inch 4.3307
Dış (D) Inch 7.874
En (B) Inch 2.748
Ağırlık 9.5 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
M Solid Brass Cage, Guided By Rollers
C3 Internal Clearance Larger Than Normal
