FAG 23226-E1-XL-TVPB-C4
Fiyatı: 13,432.43 ₺
Özellikler
| Marka | FAG |
| Ürün No | 23226-E1-XL-TVPB-C4 FAG |
| Alternatif Kodu |
23226-E1-TVPB-C4 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 130 |
| Dış (D) MM | 230 |
| En (B) MM | 80 |
| İç (d) Inch | 5.1181 |
| Dış (D) Inch | 9.0551 |
| En (B) Inch | 3.1496 |
| Ağırlık | 13.4 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Radyal İç Oyun | C4 İç Oyun (C3ten Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 80 |
| Radial Static Load Rating C0r (N) | 1150000 |
| Radial Dynamic Load Rating Cr (N) | 910000 |
| Temel statik yük derecesi, radyal (C 0r) | "1150000.0000" |
| Hız sınırlaması (n G) | 2850 |
| Referans Hızı (n u03d1r) | 1740 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 232..-E1, main dimensions to DIN 635-2 |
| E1 | Increased Capacity Design |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
| C4 | Bearing Internal Clearance Greater Than C3 |
