FAG 23972-MB-H140-C3
Fiyatı: 104,368.78 ₺
Özellikler
| Marka | FAG |
| Ürün No | 23972-MB-H140-C3 FAG |
| Kategori | Küresel Makaralı |
| İç (d) MM | 360 |
| Dış (D) MM | 480 |
| En (B) MM | 90 |
| İç (d) Inch | 14.1732 |
| Dış (D) Inch | 18.8976 |
| En (B) Inch | 3.5433 |
| Ağırlık | 46.5 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Daha Yüksek Çalışma Aks. ISO Cl.5 |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| MB | Solid Brass Cage, Guidance On Inner Ring |
| H140 | Improved Running Accuracy According to T52BW; - Highest Point Of Runout Marked On The Inner Ring And Outer Ring Face; -Circumferential Lubricating Groove And 6 Lubricating Holes In The Inner Ring; - Aluminium Plugs Provided For Plugging The Lube Holes (Only Need For Hydraulic Dismounting, 6 Smaller Plugs For Inner Ring And 3 Larger Plugs For Outer Ring) |
| C3 | Internal Clearance Larger Than Normal |
FAG 23972-MB
44.9 kg
360x480x90 mm
FAG 23972-K-MB-C3
42.7 kg
360x480x90 mm
FAG 23972-K-MB-C4
45 kg
360x480x90 mm
FAG 23972-MB-T52BW-C3
46.5 kg
360x480x90 mm
FAG 23972-K-MB-T52BW-C3
44.9 kg
360x480x90 mm
FAG 23972-K-MB
42.7 kg
360x480x90 mm
FAG 23972-MB-C3
46.5 kg
360x480x90 mm
FAG 23972K-MB
42.7 kg
360x480x90 mm
FAG 23972MB-C3
46.5 kg
360x480x90 mm
FAG 23972MB
44.9 kg
360x480x90 mm
FAG 23972K-MB-C4
45 kg
360x480x90 mm
FAG 23972MB-C3-H40A
46.5 kg
360x480x90 mm
FAG 23972-K-MB-T52BW-C4
44.9 kg
360x480x90 mm
FAG 23972-K-MB-C5
45 kg
360x480x90 mm
FAG 23972-MB-C2
44.9 kg
360x480x90 mm
FAG 23972K-MB-C3
42.7 kg
360x480x90 mm
FAG 23972-MB-C4
46.5 kg
360x480x90 mm
