FAG 24032-BE-XL-C4

FAG 24032-BE-XL-C4
FAG 24032-BE-XL-C4 rulman resim 1
FAG 24032-BE-XL-C4 rulman resim 2
FAG 24032-BE-XL-C4 rulman resim 3
FAG 24032-BE-XL-C4 rulman resim 4
Fiyatı: 17,055.79 ₺
Özellikler
Marka FAG
Ürün No 24032-BE-XL-C4 FAG
Üretici No 0590199210040
Alternatif Kodu 24032-BE-C4
EAN 4012802322682
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 160
Dış (D) MM 240
En (B) MM 80
İç (d) Inch 6.2992
Dış (D) Inch 9.4488
En (B) Inch 3.1496
Ağırlık 12.3 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 80
Radial Static Load Rating C0r (N) 1240000
Radial Dynamic Load Rating Cr (N) 770000
Temel statik yük derecesi, radyal (C 0r) "1240000.0000"
Hız sınırlaması (n G) 2550
Referans Hızı (n u03d1r) 1660
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearing 240..-BE-XL, symmetric with rib washer
Suffix description
BE Maximum Capacity Design
XL X-Life
C4 Bearing Internal Clearance Greater Than C3
