FAG 24040-BE-XL-K30
Fiyatı: 29,356.70 ₺
Özellikler
| Marka | FAG |
| Ürün No | 24040-BE-XL-K30 FAG |
| Üretici No | 0650203910000 |
| Alternatif Kodu |
24040-BE-K30 |
| EAN | 4012802485257 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 200 |
| Dış (D) MM | 310 |
| En (B) MM | 109 |
| İç (d) Inch | 7.874 |
| Dış (D) Inch | 12.2047 |
| En (B) Inch | 4.2913 |
| Ağırlık | 29.59 kg |
| Sıkıntı | K3 - 1:30 Konik Delik |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 109 |
| Radial Static Load Rating C0r (N) | 2150000 |
| Radial Dynamic Load Rating Cr (N) | 1350000 |
| Temel statik yük derecesi, radyal (C 0r) | "2150000.0000" |
| Hız sınırlaması (n G) | 2010 |
| Referans Hızı (n u03d1r) | 1240 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 240..-BE-K30, main dimensions to DIN 635-2, with tapered bore, taper 1:30 |
| BE | Maximum Capacity Design |
| XL | X-Life |
| K30 | Tapered Bore, Taper 1:30 |
