FAG 24122-BE-XL-K30-C3

FAG 24122-BE-XL-K30-C3
FAG 24122-BE-XL-K30-C3 rulman resim 1
FAG 24122-BE-XL-K30-C3 rulman resim 2
FAG 24122-BE-XL-K30-C3 rulman resim 3
FAG 24122-BE-XL-K30-C3 rulman resim 4
FAG 24122-BE-XL-K30-C3 rulman resim 5
FAG 24122-BE-XL-K30-C3 rulman resim 6
Fiyatı: 8,855.18 ₺
Özellikler
Marka FAG
Ürün No 24122-BE-XL-K30-C3 FAG
Üretici No 0585628420030
Alternatif Kodu 24122-BE-K30-C3
EAN 4012802366235
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 180
En (B) MM 69
İç (d) Inch 4.3307
Dış (D) Inch 7.0866
En (B) Inch 2.7165
Ağırlık 6.8 kg
Ürün Özellikleri
Sıkıntı K3 - 1:30 Konik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 69
Radial Static Load Rating C0r (N) 750000
Radial Dynamic Load Rating Cr (N) 530000
Hız sınırlaması (n G) 3350
Referans Hızı (n u03d1r) 1960
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 241..-BE-K30, main dimensions to DIN 635-2, with tapered bore, taper 1:30
Suffix description
BE Maximum Capacity Design
XL X-Life
K30 Tapered Bore, Taper 1:30
C3 Internal Clearance Larger Than Normal
