FAG 24124-BE-XL-H40
Fiyatı: 13,408.72 ₺
Özellikler
| Marka | FAG |
| Ürün No | 24124-BE-XL-H40 FAG |
| Alternatif Kodu |
24124-BE-H40 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 120 |
| Dış (D) MM | 200 |
| En (B) MM | 80 |
| İç (d) Inch | 4.7244 |
| Dış (D) Inch | 7.874 |
| En (B) Inch | 3.1496 |
| Ağırlık | 10.1 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W - No Lubrication Groove or Holes |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| BE | Maximum Capacity Design |
| XL | X-Life |
| H40 | Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring |
FAG 24124-BE-XL
10.1 kg
120x200x80 mm
FAG 24124-BE-XL-C3
10.7 kg
120x200x80 mm
FAG 24124-BE-XL-T52BW
10.1 kg
120x200x80 mm
FAG 24124-E1-K30-TVPB-C3
11.5 kg
120x200x80 mm
FAG 24124-BE-XL-K30-C3
11.5 kg
120x200x80 mm
FAG 24124-E1-K30-C3
11.5 kg
120x200x80 mm
FAG 24124-BE-XL-H40-C3
10.7 kg
120x200x80 mm
FAG 24124-E1-C4
10 kg
120x200x80 mm
FAG 24124-BE-XL-K30
9.78 kg
120x200x80 mm
FAG 24124-BE-XL-C4
10 kg
120x200x80 mm
FAG 24124-BE-XL-K30-C4
9.78 kg
120x200x80 mm
FAG 24124ESK30TVPB
9.78 kg
120x200x80 mm
FAG 24124ESK30-TVPB
9.78 kg
120x200x80 mm
FAG 24124S-C4
11.6 kg
120x200x80 mm
FAG 24124-BE-XL-2VSR-H40
10.4 kg
120x200x80 mm
FAG 24124ES-TVPB-C4
10 kg
120x200x80 mm
FAG 24124K-C3
10.1 kg
120x200x80 mm
FAG 24124SK30-C3
9.78 kg
120x200x80 mm
FAG 24124-S
11.6 kg
120x200x80 mm
FAG 24124S-C3
11.6 kg
120x200x80 mm
FAG 24124S
11.6 kg
120x200x80 mm
FAG 24124ES-TVPB
10.1 kg
120x200x80 mm
FAG 24124-E1
10.1 kg
120x200x80 mm
FAG 24124-S-C3
11.6 kg
120x200x80 mm
FAG 24124HL
10.1 kg
120x200x80 mm
FAG 24124-E1-TVPB
10.1 kg
120x200x80 mm
FAG 24124ESK30TVPB-C3
11.5 kg
120x200x80 mm
FAG 24124-E1-C3
10.7 kg
120x200x80 mm
FAG 24124-E1-K30
9.78 kg
120x200x80 mm
FAG 24124E1K30TVPB-C3
11.5 kg
120x200x80 mm
