FAG 24126-BE-XL-2VSR-H40-C4
Fiyatı: 27,677.52 ₺
Özellikler
| Marka | FAG |
| Ürün No | 24126-BE-XL-2VSR-H40-C4 FAG |
| Üretici No | 0825989240040 |
| Alternatif Kodu |
24126-BE-2VSR-H40-C4 |
| EAN | 4054371818456 |
| Kategori | Küresel Makaralı |
| İç (d) MM | 130 |
| Dış (D) MM | 210 |
| En (B) MM | 80 |
| İç (d) Inch | 5.1181 |
| Dış (D) Inch | 8.2677 |
| En (B) Inch | 3.1496 |
| Ağırlık | 10.7 kg |
| Sıkıntı | C - Silindirik Delik |
| Yağlama Enhancement | W - No Lubrication Groove or Holes |
| Fok | 2RS2 - Floro Kauçuk Contalar / Yüksek Sıcaklık |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Radyal İç Oyun | C4 İç Oyun (C3ten Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Genişlik (b) mm | 80 |
| Temel statik yük derecesi, radyal (C 0r) | 1050000 |
| Hız sınırlaması (n G) | 700 |
| BE | Maximum Capacity Design |
| XL | X-Life |
| 2VSR | Sheet Steel Reinforced Rubbing Seals Of Fluoro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Plyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring |
| H40 | Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring |
| C4 | Bearing Internal Clearance Greater Than C3 |
