FAG 24128-BE-XL-K30

FAG 24128-BE-XL-K30
FAG 24128-BE-XL-K30 rulman resim 1
FAG 24128-BE-XL-K30 rulman resim 2
FAG 24128-BE-XL-K30 rulman resim 3
FAG 24128-BE-XL-K30 rulman resim 4
FAG 24128-BE-XL-K30 rulman resim 5
Fiyatı: 18,131.98 ₺
Özellikler
Marka FAG
Ürün No 24128-BE-XL-K30 FAG
Üretici No 0586821980000
Alternatif Kodu 24128-BE-K30
EAN 4012802366266
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 140
Dış (D) MM 225
En (B) MM 85
İç (d) Inch 5.5118
Dış (D) Inch 8.8583
En (B) Inch 3.3465
Ağırlık 11.8 kg
Ürün Özellikleri
Sıkıntı K3 - 1:30 Konik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 85
Radial Static Load Rating C0r (N) 1190000
Radial Dynamic Load Rating Cr (N) 800000
Temel statik yük derecesi, radyal (C 0r) "1190000.0000"
Hız sınırlaması (n G) 2650
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 241..-BE-K30, main dimensions to DIN 635-2, with tapered bore, taper 1:30
Suffix description
BE Maximum Capacity Design
XL X-Life
K30 Tapered Bore, Taper 1:30
