FAG 31309-XL
Fiyatı: 1,292.10 ₺
Özellikler
| Marka | FAG |
| Ürün No | 31309-XL FAG |
| Üretici No | 0849956880000 |
| Alternatif Kodu |
31309 |
| EAN | 4054369724011 |
| Kategori | Konik Makaralı - Tek Sıra |
| İç (d) MM | 45 |
| Dış (D) MM | 100 |
| En (B) MM | 27,25 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 3.937 |
| En (B) Inch | 1.0728 |
| Ağırlık | 0.95 kg |
| Kesinlik | Standart Hassasiyet |
| Radial Static Load Rating C0r (N) | 108000 |
| Width inner ring (B) mm | 25 |
| Radial Dynamic Load Rating Cr (N) | 114000 |
| Temel statik yük derecesi, radyal (C 0r) | "108000.0000" |
| Hız sınırlaması (n G) | 8600 |
| Width, total (T) mm | 27,25 |
| Thermal speed rating (n u03d1r) | 4650 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| Medias description | Tapered roller bearings 313, main dimensions to DIN ISO 355 / DIN 720, separable, adjusted or in pairs |
| XL | X-Life |
