FAG 32009-X-XL-P5
Fiyatı: 805.38 ₺
Özellikler
| Marka | FAG |
| Ürün No | 32009-X-XL-P5 FAG |
| Üretici No | 0859851710000 |
| Alternatif Kodu |
32009-X-P5 |
| EAN | 4054364790745 |
| Kategori | Konik Makaralı - Tek Sıra |
| İç (d) MM | 45 |
| Dış (D) MM | 75 |
| En (B) MM | 20 |
| İç (d) Inch | 1.7717 |
| Dış (D) Inch | 2.9528 |
| En (B) Inch | 0.7874 |
| Ağırlık | 0.365 kg |
| Kesinlik | P5 Hassasiyeti (P6dan Yüksek) |
| Width inner ring (B) mm | 20 |
| Temel statik yük derecesi, radyal (C 0r) | 86000 |
| Hız sınırlaması (n G) | 11400 |
| Width, total (T) mm | 20 |
| Thermal speed rating (n u03d1r) | 5400 |
| ECLASS number | 23-05-09-10 |
| ECLASS2 number | 23-05-09-10 |
| X | External Dimensions Matched To International Standards |
| XL | X-Life |
| P5 | Dimensional And Running Accuracy To ISO Tolerance Class 5 |
