FAG 3205-BD-XL-2HRS
Fiyatı: 1,075.15 ₺
Özellikler
| Marka | FAG |
| Ürün No | 3205-BD-XL-2HRS FAG |
| Üretici No | 0822712590000 |
| Alternatif Kodu |
3205-BD-2HRS |
| EAN | 4054366900883 |
| Kategori | Çift Sıra - Açısal Temaslı |
| İç (d) MM | 25 |
| Dış (D) MM | 52 |
| En (B) MM | 20,6 |
| İç (d) Inch | 0.9843 |
| Dış (D) Inch | 2.0472 |
| En (B) Inch | 0.811 |
| Ağırlık | 0.177 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | 2RH - İki Tarafta Yüksek Hızlı Düşük Sürtünmeli Conta |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Yağlama | Standart Yağlama |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Split Inner ring / Outer ring | Standard |
| Genişlik (b) mm | 20,6 |
| Radial Static Load Rating C0r (N) | 15200 |
| Radial Dynamic Load Rating Cr (N) | 22000 |
| Temel statik yük derecesi, radyal (C 0r) | "15200.0000" |
| Hız sınırlaması (n G) | 10700 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 32..-BD-XL-2HRS, double row, 1 inner ring |
| BD | Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot |
| XL | X-Life |
| 2HRS | Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
