FAG 3307-BD-XL-2HRS-TVH
Fiyatı: 1,795.87 ₺
Özellikler
| Marka | FAG |
| Ürün No | 3307-BD-XL-2HRS-TVH FAG |
| Üretici No | 0638742290000 |
| Alternatif Kodu |
3307-BD-2HRS-TVH |
| EAN | 4012802478143 |
| Kategori | Çift Sıra - Açısal Temaslı |
| İç (d) MM | 35 |
| Dış (D) MM | 80 |
| En (B) MM | 34,9 |
| İç (d) Inch | 1.378 |
| Dış (D) Inch | 3.1496 |
| En (B) Inch | 1.374 |
| Ağırlık | 0.729 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | 2RH - İki Tarafta Yüksek Hızlı Düşük Sürtünmeli Conta |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | Standart Hassasiyet |
| Yağlama | Standart Yağlama |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Split Inner ring / Outer ring | Standard |
| Genişlik (b) mm | 34,9 |
| Radial Static Load Rating C0r (N) | 36500 |
| Radial Dynamic Load Rating Cr (N) | 55000 |
| Temel statik yük derecesi, radyal (C 0r) | "36500.0000" |
| Hız sınırlaması (n G) | 6800 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 33..-BD-2HRS, main dimensions to DIN 628-3, double row, lip seals on both sides, contact angle a = 30° |
| BD | Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot |
| XL | X-Life |
| 2HRS | Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| TVH | Moulded Polyamide Cage Snap-Type, Rolling Element Riding |
