FAG 6020-M-C3

FAG 6020-M-C3
FAG 6020-M-C3 rulman resim 1
FAG 6020-M-C3 rulman resim 2
FAG 6020-M-C3 rulman resim 3
FAG 6020-M-C3 rulman resim 4
Fiyatı: 3,225.25 ₺
Özellikler
Marka FAG
Ürün No 6020-M-C3 FAG
Üretici No 0383820320030
EAN 4012801077279
Kategori Tek Sıra - Derin Oluklu
Ağırlık ve Boyutlar
İç (d) MM 100
Dış (D) MM 150
En (B) MM 24
İç (d) Inch 3.937
Dış (D) Inch 5.9055
En (B) Inch 0.9449
Ağırlık 1.56 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Dış Modifikasyon Harici Modifikasyon Yok
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Yağlama Standart Yağlama
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Özel Muamele No Special Treatment
Data from Schaeffler (medias)
Genişlik (b) mm 24
Radial Static Load Rating C0r (N) 54000
Radial Dynamic Load Rating Cr (N) 64000
Temel statik yük derecesi, radyal (C 0r) "54000.0000"
Hız sınırlaması (n G) 7900
Referans Hızı (n u03d1r) 5100
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 60..-M, single row, cf. DIN 625-1
Suffix description
M Solid Brass Cage, Ball-Guided
C3 Internal Clearance Larger Than Normal
