FAG 607-2Z-HLC-C3

FAG 607-2Z-HLC-C3
FAG 607-2Z-HLC-C3 rulman resim 1
FAG 607-2Z-HLC-C3 rulman resim 2
FAG 607-2Z-HLC-C3 rulman resim 3
Fiyatı: 41.60 ₺
Özellikler
Marka FAG
Ürün No 607-2Z-HLC-C3 FAG
Üretici No 0554489170030
Alternatif Kodu 607-2Z-C3
EAN 4012802607437
Kategori Tek Sıra - Derin Oluklu
Ağırlık ve Boyutlar
İç (d) MM 7
Dış (D) MM 19
En (B) MM 6
İç (d) Inch 0.2756
Dış (D) Inch 0.748
En (B) Inch 0.2362
Ağırlık 0.007 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Fok ZZ/2Z - İki Tarafta Çelik Conta
Kasa Tipi S - Çelik veya Standart Kafes
Dış Modifikasyon Harici Modifikasyon Yok
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Yağlama Standart Yağlama
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Özel Muamele No Special Treatment
Data from Schaeffler (medias)
Genişlik (b) mm 6
Radial Static Load Rating C0r (N) 889
Radial Dynamic Load Rating Cr (N) 2340
Hız sınırlaması (n G) 45500
Referans Hızı (n u03d1r) 37000
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearings 60..-2Z, main dimensions to DIN 625-1, gap seals on both sides
Suffix description
2Z Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal)
HLC Factory Location Code, No Additional Meaning, Can Be Used As Standard
C3 Internal Clearance Larger Than Normal
