FAG 609-2RS-HLC-C3
Fiyatı: 77.79 ₺
Özellikler
| Marka | FAG |
| Ürün No | 609-2RS-HLC-C3 FAG |
| Alternatif Kodu |
609-2RS-C3 |
| Kategori | Tek Sıra - Derin Oluklu |
| İç (d) MM | 9 |
| Dış (D) MM | 24 |
| En (B) MM | 7 |
| İç (d) Inch | 0.3543 |
| Dış (D) Inch | 0.9449 |
| En (B) Inch | 0.2756 |
| Ağırlık | 0.014 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | 2RS - İki Tarafta Kauçuk Conta |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Yağlama | Standart Yağlama |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Özel Muamele | No Special Treatment |
| Radial Static Load Rating C0r (N) | 1444 |
| Radial Dynamic Load Rating Cr (N) | 3350 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 60..-2RS, single row, cf. DIN 625-1 |
| 2RS | Rubber Seals At Each Side Of The Bearing |
| HLC | Factory Location Code, No Additional Meaning, Can Be Used As Standard |
| C3 | Internal Clearance Larger Than Normal |
