FAG 6206-C-2HRS-L100-C3
Fiyatı: 271.86 ₺
Özellikler
| Marka | FAG |
| Ürün No | 6206-C-2HRS-L100-C3 FAG |
| Üretici No | 0956625370030 |
| Alternatif Kodu |
6206-2HRS-L100-C3 |
| EAN | 4064327005571 |
| Kategori | Tek Sıra - Derin Oluklu |
| İç (d) MM | 30 |
| Dış (D) MM | 62 |
| En (B) MM | 16 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 2.4409 |
| En (B) Inch | 0.6299 |
| Ağırlık | 0.192 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | 2RH - İki Tarafta Yüksek Hızlı Düşük Sürtünmeli Conta |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Yağlama | Standart Yağlama |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Özel Muamele | No Special Treatment |
| Radial Static Load Rating C0r (N) | 11300 |
| Radial Dynamic Load Rating Cr (N) | 20800 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 62..-C-2HRS, single row, cf. DIN 625-1 |
| C | Deep Groove Ball Bearings Of Generation C, Modified Internal Construction |
| 2HRS | Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| L100 | High/Low Temperature Grease -40ºC/+160ºC |
| C3 | Internal Clearance Larger Than Normal |
