FAG 6220-M-J20AA-C3

FAG 6220-M-J20AA-C3
FAG 6220-M-J20AA-C3 rulman resim 1
FAG 6220-M-J20AA-C3 rulman resim 2
FAG 6220-M-J20AA-C3 rulman resim 3
FAG 6220-M-J20AA-C3 rulman resim 4
Fiyatı: 17,056.00 ₺
Özellikler
Marka FAG
Ürün No 6220-M-J20AA-C3 FAG
Üretici No 0390140290030
EAN 4054364843045
Kategori Tek Sıra - Derin Oluklu
Ağırlık ve Boyutlar
İç (d) MM 100
Dış (D) MM 180
En (B) MM 34
İç (d) Inch 3.937
Dış (D) Inch 7.0866
En (B) Inch 1.3386
Ağırlık 3.8 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Dış Modifikasyon Harici Modifikasyon Yok
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Bozulma Voltajı 1000v
Yağlama Standart Yağlama
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Özel Muamele No Special Treatment
Data from Schaeffler (medias)
Genişlik (b) mm 34
Radial Static Load Rating C0r (N) 93000
Radial Dynamic Load Rating Cr (N) 130000
Temel statik yük derecesi, radyal (C 0r) "93000.0000"
Hız sınırlaması (n G) 6500
Referans Hızı (n u03d1r) 4800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-M-J20AA, single row, cf. DIN 625-1
Suffix description
M Solid Brass Cage, Ball-Guided
J20AA Coating Which Consists Of Oxide Ceramic, It Is Applied By Plasma Spraying And Then Sealed With Synthetic Resin. Speciality Humid Environments
C3 Internal Clearance Larger Than Normal
