FAG 6313-H-2Z-SN-C3

FAG 6313-H-2Z-SN-C3
FAG 6313-H-2Z-SN-C3 rulman resim 1
FAG 6313-H-2Z-SN-C3 rulman resim 2
FAG 6313-H-2Z-SN-C3 rulman resim 3
Fiyatı: 1,643.41 ₺
Özellikler
Marka FAG
Ürün No 6313-H-2Z-SN-C3 FAG
Alternatif Kodu 6313-C-2Z-C3
Kategori Tek Sıra - Derin Oluklu
Ağırlık ve Boyutlar
İç (d) MM 65
Dış (D) MM 140
En (B) MM 33
İç (d) Inch 2.5591
Dış (D) Inch 5.5118
En (B) Inch 1.2992
Ağırlık 2.14 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Fok ZZ/2Z - İki Tarafta Çelik Conta
Kasa Tipi S - Çelik veya Standart Kafes
Dış Modifikasyon Harici Modifikasyon Yok
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Yağlama Standart Yağlama
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Özel Muamele No Special Treatment
Data from Schaeffler (medias)
Genişlik (b) mm 33
Radial Static Load Rating C0r (N) 60000
Radial Dynamic Load Rating Cr (N) 97500
Temel statik yük derecesi, radyal (C 0r) "60000.0000"
Hız sınırlaması (n G) 5600
Referans Hızı (n u03d1r) 6300
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearings 63..-H-2Z, main dimensions to DIN 625-1, gap seals on both sides
Suffix description
H Basic Quality
2Z Two Metallic Shields
SN The Rings Of The Bearing Are Dimensional Stabilised To 120°C
C3 Internal Clearance Larger Than Normal
