FAG 7224-B-XL-MP-P5-UO

FAG 7224-B-XL-MP-P5-UO
FAG 7224-B-XL-MP-P5-UO rulman resim 1
FAG 7224-B-XL-MP-P5-UO rulman resim 2
FAG 7224-B-XL-MP-P5-UO rulman resim 3
FAG 7224-B-XL-MP-P5-UO rulman resim 4
Fiyatı: 27,277.33 ₺
Özellikler
Marka FAG
Ürün No 7224-B-XL-MP-P5-UO FAG
Üretici No 0191161440000
Alternatif Kodu 7224-B-MP-P5-UO
EAN 4012801283144
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 120
Dış (D) MM 215
En (B) MM 40
İç (d) Inch 4.7244
Dış (D) Inch 8.4646
En (B) Inch 1.5748
Ağırlık 6.08 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Kesinlik P5 Hassasiyeti (P6dan Yüksek)
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 40
Radial Static Load Rating C0r (N) 178000
Radial Dynamic Load Rating Cr (N) 182000
Temel statik yük derecesi, radyal (C 0r) "178000.0000"
Hız sınırlaması (n G) 5200
Referans Hızı (n u03d1r) 3700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
