FAG 7234-B-MP-UO
Fiyatı: 37,380.10 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7234-B-MP-UO FAG |
| Üretici No | 0190032770000 |
| EAN | 4012801572101 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 170 |
| Dış (D) MM | 310 |
| En (B) MM | 52 |
| İç (d) Inch | 6.6929 |
| Dış (D) Inch | 12.2047 |
| En (B) Inch | 2.0472 |
| Ağırlık | 18 kg |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Kesinlik | Standart Hassasiyet |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UO - Zero Clearance |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 52 |
| Radial Static Load Rating C0r (N) | 355000 |
| Radial Dynamic Load Rating Cr (N) | 270000 |
| Temel statik yük derecesi, radyal (C 0r) | "355000.0000" |
| Hız sınırlaması (n G) | 3250 |
| Referans Hızı (n u03d1r) | 2440 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 72..-B-MP, single row |
| B | 40° Contact Angle |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| UO | Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance |
