FAG 7317-B-XL-JP-UO
Fiyatı: 9,023.46 ₺
Özellikler
| Marka | FAG |
| Ürün No | 7317-B-XL-JP-UO FAG |
| Alternatif Kodu |
7317-B-JP-UO |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 85 |
| Dış (D) MM | 180 |
| En (B) MM | 41 |
| Ağırlık | 4.259 kg |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Kesinlik | Standart Hassasiyet |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UO - Zero Clearance |
| Yağlama | Standart Yağlama |
| Radial Static Load Rating C0r (N) | 138000 |
| Radial Dynamic Load Rating Cr (N) | 167000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 73..-B-XL-JP, single row |
| B | 40° Contact Angle |
| XL | X-Life |
| JP | Pressed Steel Cage, Rolling Element Guided |
| UO | Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance |
