FAG B7010-C-T-P4S-UM

FAG B7010-C-T-P4S-UM
FAG B7010-C-T-P4S-UM rulman resim 1
FAG B7010-C-T-P4S-UM rulman resim 2
FAG B7010-C-T-P4S-UM rulman resim 3
FAG B7010-C-T-P4S-UM rulman resim 4
FAG B7010-C-T-P4S-UM rulman resim 5
FAG B7010-C-T-P4S-UM rulman resim 6
Fiyatı: 4,577.46 ₺
Özellikler
Marka FAG
Ürün No B7010-C-T-P4S-UM FAG
Üretici No 0191508900000
Alternatif Kodu 7010CDGB/P4A
EAN 4026677530325
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 80
En (B) MM 16
İç (d) Inch 1.9685
Dış (D) Inch 3.1496
En (B) Inch 0.6299
Ağırlık 0.26 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 16
Radial Static Load Rating C0r (N) 16100
Radial Dynamic Load Rating Cr (N) 29000
Temel statik yük derecesi, radyal (C 0r) "16100.0000"
Limiting speed for grease lubrication (n G Grease) 18000
Limiting speed for oil lubrication (n G Oil) 28000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
