FAG B7012-E-T-P4S-QBCL
Fiyatı: 20,853.66 ₺
Özellikler
| Marka | FAG |
| Ürün No | B7012-E-T-P4S-QBCL FAG |
| Üretici No | 0384340320000 |
| Alternatif Kodu |
7012ACD/P4AQBCA |
| EAN | 4012801449434 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 60 |
| Dış (D) MM | 95 |
| En (B) MM | 72 |
| İç (d) Inch | 2.3622 |
| Dış (D) Inch | 3.7402 |
| En (B) Inch | 2.8346 |
| Ağırlık | 1.6 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 25 degrees |
| Pairing | QBC - O-arrangement, 4 |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 18 |
| Temel statik yük derecesi, radyal (C 0r) | 22600 |
| Limiting speed for grease lubrication (n G Grease) | 13000 |
| Limiting speed for oil lubrication (n G Oil) | 20000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| QBCL | Four Bearings In O Arrangement <<>> |
FAG B7012-E-T-P4S-QUL
1.6 kg
60x95x72 mm
