FAG B7012-E-T-P4S-UM

FAG B7012-E-T-P4S-UM
FAG B7012-E-T-P4S-UM rulman resim 1
FAG B7012-E-T-P4S-UM rulman resim 2
FAG B7012-E-T-P4S-UM rulman resim 3
FAG B7012-E-T-P4S-UM rulman resim 4
Fiyatı: 5,519.49 ₺
Özellikler
Marka FAG
Ürün No B7012-E-T-P4S-UM FAG
Üretici No 0191512840000
Alternatif Kodu 7012ACDGB/P4A
EAN 4012801449526
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 60
Dış (D) MM 95
En (B) MM 18
İç (d) Inch 2.3622
Dış (D) Inch 3.7402
En (B) Inch 0.7087
Ağırlık 0.4 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 18
Radial Static Load Rating C0r (N) 22600
Radial Dynamic Load Rating Cr (N) 38000
Temel statik yük derecesi, radyal (C 0r) "22600.0000"
Limiting speed for grease lubrication (n G Grease) 13000
Limiting speed for oil lubrication (n G Oil) 20000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
